HNC848D CNC Controller
HNC848D is a 5 axis CNC Controller
With 10.4 inch color LCD display
Support NCUC bus protocol
5-32 axis control
15" color LCD screen
Used for Five-axis machine, heavy-duty machine, lathe mill combo
What can you get by purchasing it?
Service response within 24 hours
- INC cloud provides remote diagnosis and monitoring
- Local or remote service supported by engineer with fluent English or Local language
Support return policy
- Support return within 12 months' warranty.
- Complete replacement within 40 working days.
- Constant temperature production workshop
- 5 strict production test before final product
- Powered by HCNC group since 1958, stock market:300161
- Endorsement by our customers.
Functions of HNC848D CNC Controller
Make sure to give you an economic solution with cnc controller kits including servo drive, servo motor, spindle motor.
Get a quotation; send an message NOW!
|Item||Specification||HNC-848 DM||HNC-848 DT|
|Maximum number of simultaneously controlled axes in channel||9||9|
|Maximum number of feed axes||32||32|
|Maximum number of spindles in channel||4||4|
|Number of PMC control axes||32||32|
|Number of channels||Standard||1||1|
|Maximum number of axes in simultaneous motion||80||20|
|Maximum number of feed axes||64||64|
|Maximum number of simultaneously controlled axes/channel||9||3|
|Number of input/output points at maximum||4096/4096|
|Axis name (single channel)||Three basic axes: X, Y, Z; additional axes: U, V, W, A, B, C||√||―|
|Two basic axes: X, Z; additional axes: Y, U, V, W, A, B, C||―||√|
|Axis name (multi-channel)||One or two characters plus number, the first must be a character, e.g. X1||√||√|
|Gantry axis synchronization||√|
|Tangent synchronization control||★||★|
|Basic axis coupling control||★||★|
|Electronic gear box||★||★|
|Inclined axis control||★||★|
|Minimum input unit||mm, deg, inch||10-6|
|Pulse unit input||G22||√||√|
|Spatial protection area||Providing protection for workpiece and tool||★||★|
|Dynamic axis release/capture||G101/G102||√||√|
|Synchronization between channels||G104.0 to G104.7||√||√|
